Waterbox Clear Gen2
CLEAR
| PRODUCT MODEL | CLEAR 2420 | CLEAR 3620 | CLEAR 4820 | CLEAR 6025 | CLEAR 7225 | |
|---|---|---|---|---|---|---|
| Aquarium | Dimensions (Length x Width x Height) |
600 x 500 x 450mm | 900 x 500 x 450mm | 1200 x 500 x 500mm | 1536 x643 x 550mm | 1836 x 643 x 600mm |
| 23.4"×19.7"×17.7" | 35.4"×19.7"×17.7" | 47.2"×19.7"×19.7" | 60.5"×25.3"×21.7" | 72.3"×25.3"×23.6" | ||
| Glass Thickness | 8mm (5/16") | 10mm (2/5") | 12mm (1/2") | 15mm (3/5″) | 19mm (3/4") | |
| Aquarium Volume | 125 L/33 gals | 186 L/49.1 gals | 273 L/72.2 gals | 494 L/130.5 gals | 632 L/167 gals | |
| Aquarium Weight | 27.0 kg / 59.5 lb | 44.5 kg / 98.1 lb | 70.0 kg / 154.3 lb | 145.0 kg / 319.7 lb | 194.0 kg / 427.7 lb | |
| Glass Material | Ultra-clear glass | |||||
| Transmittance | 91% | |||||
| EVA Mat | 1 | 1 | 1 | 1 | 1 | |
| Cabinet | Cabinet Model | ALU 2420 | ALU 3620 | ALU 4820 | MSII 6025 | MSII 7225 |
| Dimensions (Length x Width x Height) |
600 x 500 x 900mm | 900 x 500 x 900mm | 1,200 x 500 x 900mm | 1,536 x 643 x 927mm | 1,836 x 643 x 927mm | |
| 23.6" × 19.7" × 35.4" | 35.4" × 19.7" × 35.4" | 47.2" × 19.7" × 35.4" | 60.5" × 25.3" × 36.5" | 72.3" × 25.3" × 36.5" | ||
| Cabinet Framework | Anti-corrosion Aluminum Alloy | |||||
| Door & Side Panels | 18mm PVC Laminated Wood Particle Board | |||||
| Bottom Panels | 10mm PVC Board | |||||
| Back Panels | 6mm PVC Board | |||||
| Cabinet Color | WHT-White, BLK-Black, ASP-Aspen | |||||
| SUS304 Hinges | ||||||
| Leveling Feet | ||||||
| System | Height with Cabinet | 1350mm/53.1" | 1350mm/53.1" | 1400mm/55.1" | 1477mm/58.1" | 1527mm/60.1" |
* All volumes are calculated from net tank dimension less the glass thickness. They may vary dependent on user configuration and system application.
** All specifications are subject to changes without prior notice.
